公共建筑节能设计标准

Summary

Main Activities:

1. Standard Implementation Survey:

   • The work team organized local implementation surveys in three regions: South (April 16), East (May 7), and North (June 6).
   • Over 80 experts from 11 provinces, municipalities, and autonomous regions participated in these seminars.
   • They identified the main problems and valuable suggestions in the implementation of the standard over the past seven years.

2. Revision Preparation:

   • The main technical content for revision was determined based on the survey results.
   • A draft outline for the revision was proposed.
   • Key research topics supporting the revision were identified.
   • A preliminary revision team was formed, and a division of labor was suggested.

3. Review of Envelope Performance:

   • A small-scale questionnaire survey was conducted on envelope performance evaluation.
   • Based on the survey results, the revision plan for envelope performance evaluation was outlined.

4. Standard Revision Kick-off Meeting:

   • The revision team was established and the first meeting was held on June 26, 2012, in Beijing.
   • Participants included representatives from the Ministry of Housing and Urban-Rural Development, the Chinese Academy of Building Science, and other relevant experts.
   • The revision outline and key research topics were finalized.

5. US Study Tour:

   • A delegation visited the US to study building energy standards from July 29 to August 9, 2012.
   • They visited various research institutions and laboratories, including the National Renewable Energy Laboratory, Florida Solar Energy Center, and Lawrence Berkeley National Laboratory.
   • They discussed topics such as energy simulation software, performance evaluation methods, and ASHRAE 90.1 standards.

6. Building Model Database Construction:

   • A database of typical public buildings was constructed, covering different types of buildings like large and small office buildings, hotels, hospitals, schools, and shopping malls.
   • Detailed models were created for each type of building, including functional zoning and HVAC systems.
   • The database provides a comprehensive representation of existing public buildings in China.

7. Cold Source Evaluation Method Improvement:

   • The existing evaluation method for air conditioning systems was reviewed and improved.
   • A new IPLV formula was developed based on the public building model database.
   • Different climate zones and building types were considered to set appropriate energy efficiency limits.

8. Energy Saving Targets Determination:

   • Various energy-saving measures were analyzed to determine the optimal investment-to-savings ratio.
   • A method was developed to ensure that the investment cost and energy savings are balanced.
   • The savings rate and minimum investment growth rate were correlated.

Key Achievements:

1. Survey Report: "Investigation Report on the Revision of the National Standard for Public Building Energy Efficiency."
2. Envelope Performance Report: "Research Report on the Survey and Summarization of Envelope Performance."
3. Kick-off Meeting Minutes: "Minutes of the First Meeting of the Public Building Energy Efficiency Design Standard Revision Team."
4. US Study Report: "Report on the Study Tour of US Building Energy Standards."
5. Building Model Database: "Research on Typical Public Building Models in China."
6. Energy Efficiency Evaluation Methods: "Research Report on Evaluation Methods and Limitations for Energy-Efficient Building Equipment and Products."
7. SIR Optimization Method: "Application of SIR Combination Optimization Screening Method in Public Building Energy Efficiency Standards."

Challenges:

1. Time and Resource Constraints: The revision needs to be completed by the end of 2013, which is challenging given the limited time and resources.
2. Data Availability: Insufficient national-level data hinders the accuracy of the study.
3. Increased Workload: The workload for energy-efficient design has increased significantly, impacting the quality and effectiveness of implementation.

Policy Recommendations:

1. Further Standardization of Envelope Performance Evaluation: More time and resources should be allocated to improve the standardization process.
2. Professional Data Collection: Establishing professional and routine statistical systems for building data.
3. Balanced Macro and Technical Considerations: Both macroeconomic and technical aspects should be considered when determining energy-saving targets.
